Rittal, headquartered in Herborn, Hesse, Germany, is a leading global provider of solutions for industrial enclosures, power distribution, climate control and IT infrastructure, as well as software and services. Rittal solutions can be found in more than 90 percent of all industrial sectors worldwide.

Systems made by Rittal are deployed across a variety of industrial and IT applications, including vertical sectors such as the transport industry, power generation, mechanical and plant engineering, IT and telecommunications. Rittal is active worldwide with 9,700 employees and 58 subsidiaries. Its broad product range includes infrastructure solutions for modular and energy-efficient data centres with innovative concepts for the security of physical data and systems. Leading software providers Eplan and Cideon complement the value chain, providing interdisciplinary engineering solutions, while Rittal Automation Systems offers automation systems for switchgear construction.

Founded in Herborn in 1961 and still run by its owner, Rittal is the largest company in the Friedhelm Loh Group. The Friedhelm Loh Group operates worldwide with 12 production sites and 96 international subsidiaries. The entire group employs 12,100 people and generated revenues of €2.6 billion in 2019. For the twelfth time in succession, the family business has won the accolade “Top German Employer” in 2020. In addition, Friedhelm Loh Group was recognized as “Top vocational trainer” according to a study of Deutschland Test and Focus Money for the fifth year running in 2020.

Further information can be found at www.rittal.com and www.friedhelm-loh-group.com.


Anixter and Rittal joined forces systematically in 2016 signing a global Master Sales Agreement and since then develop a global strategic Alliance relationship with a concerted market approach, systematic development of global key accounts and joint sales and marketing activities.

The companies have developed joint solutions like for Edge Data Centres (DC) or IT Containers and continue to strive to create new solutions. Customer feedback from both, the IT and industry business on the solutions is extremely positive and they are convinced of their value proposition and competitiveness.


IT Infrastructure Solutions

The digital transformation is revolutionising production. To control production in line with Industry 4.0, all components are now interlinked and communicate with one another: robots, human/machine interfaces, sensors and actuators, machines, tools and control systems. Their values are compared against their digital twin. This generates vast volumes of data. That’s where decentralized Edge Data Centres come in in addition to Hyperscale and Colocations DCs.

Rittal and Anixter provide customized Data Center solutions like “Rack & Stack Offerings”, Smart Rack offerings for Colocation, Industrial Rack packages for industrial environments, Outdoor solutions for Telco, and Container solutions for global System Integrators.


Industry Infrastructure Solutions

The key to greater productivity in enclosure manufacturing lies in digital integration and end-to-end data transfer across the entire value chain. Digital prototyping from the outset, with the digital twin at its heart, provides the basis for rapid links between processes, systems and beyond.

Rittal and Anixter provide industrial enclosures as well as wall-mounted enclosures with a unique range of accessories for system integration, power distributions and climate control. Various configurators exist to select your right package. The products are available globally.


Date: 21.07.2020
More transparency and control over power consumption in IT racks
Energy consumption is an important factor for economical IT operations. The maximum transparency of consumption is vital. That is why Rittal has integrated extensive measurement functions for detailed energy analysis in its new PDU (Power Distribution Unit) product range. Intelligent variants also support switching per output and the connection of access controls. The PDUs can be configured online, which lets IT users implement high-quality power distribution quickly and easily within any IT rack, based on their individual requirements. With its intelligent power distribution system, Rittal has significantly enhanced its IT infrastructure range, which covers IT cooling, monitoring, physical security and turnkey data centres including cloud services to meet the IT world’s future demands.

Date: 14.07.2020
AX enclosures: now also ready for outdoor use
Rittal has rounded off its AX range of compact enclosures with its newly developed plastic enclosures. The manufacturer is now offers the best of two worlds: the advantages of sophisticated technology combined with the benefits of an extremely robust material. The AX plastic enclosure protects the electrical components even in very harsh environments, such as outdoors. Its new mounting functions make rapid expansion possible and provide a greater scope for installation using smart technology.

Date: 25.02.2020
5G at Rittal: The new mobile communication standard finds its way into manufacturing
Rittal is one of the first industrial players to receive a 5G frequency allocation. Before the end of the year, a private 5G mobile communications network will be installed in the new Haiger plant. The first pilot projects, for example in production monitoring and analysis, have already been defined.

Solution Examples

The performance and security of any IT infrastructure is determined to a significant degree by the interaction between individual components. All system components in the Rittal system platform are perfectly coordinated with one another.

Large volumes of data generated in the immediate production environment must be processed quickly and reliably. To this end, Rittal offers customized DC solutions from small to big as well as packaged, in room or in containers or high availability security rooms.

Additionally, Anixter customers can use the wide range of edge data centre packages, for IT to be everywhere in critical or uncritical environments.  These ensure low IT at site, where it´s generated for applications that demand low latencies, maximum computing power and optimum security.



Back to top

IT in general infrastructure environment

IT components for modern infrastructures
If you want to assemble and expand a modular IT system, step by step, you have come to the right place. The RiMatrix system from Rittal offers a huge range of components for flexible configuration of forward-looking data centre infrastructures.

IT in general infrastructure environment Image

Examples of pre-defined solution packages.
Flatbox" 9 Units, 600mm depth
TS IT" 24 Units, 600mm depth
AX IT" 15 Units, 350mm depth

Benefits at a glance

Network/server enclosures

  • For individual use as stand-alone installations and data centres
  • Complete system solutions for small to large networks
  • Maximum configuration versatility and protection for installed equipment
  • Simple conversions and use of our extensive modular system enclosures


Wall-mounted enclosures

  • A comprehensive choice of products – the right enclosure for every application – up to protection category IP 66
  • Wide range of sizes available from 3 U to 21 U
  • Extensive selection of accessories with "Rittal – The System."
  • Fast assembly, modification and simple installation based on the modular principle




Back to top

IT in industrial environment

IoT applications demand Edge solutions on premise, where the data is generated like in manufacturing, industrial operations, building management, retail. Edge Data Center can handle a wide variety of tasks, not just data capture and condition monitoring. With critical processes, such as controlling traffic flows or monitoring production processes, it is particularly vital for an edge data centre to reflect the availability of the application. Scalable redundancy is the key here.

IT in industrial environment Image

Benefits at a glance

  • Interfaces to all sensors, machines and devices
  • Low latency in critical applications
  • Capture and analysis of unstructured data to avoid unnecessary transmission to the cloud
  • Interface to other edge data centres and to superimposed services in the cloud
  • Efficient plug & play cooling solution with no installation work required


Rittal offers the matching housing for critical environments like industry, outdoor, retail or telecommunications. It is easy to upsell IT equipment with the right, smart and attractive IT Infrastructure for additional business. And there is no hassle as Anixter and Rittal have predefined Edge Packages for this.

Examples of pre-defined solution packages.
Edge Data Center 24 Units, 1000mm depth
Edge Data Center 42 Units, 1000mm depth



Back to top

IT in critical environment

Rittal offers the right protection concept for every business security requirement. As well as security rooms, micro data centres provide optimum protection against potential physical threats to your IT. The compact safes are particularly ideal as a protection concept for small and medium-sized enterprises, by providing physical cover for individual server racks. Our solutions have system tested quality which means that the entire solution has been tested for fire protection, intruder protection, smoke protection and water/dust-tightness in accordance with the specified standards. Across all systems, the 482.6 mm (19’’) fire alarm and extinguisher systems offer optimum fire protection in closed server enclosures. These systems are readily incorporated into the CMC III monitoring system via CAN bus interface.


IT in Critical Environment Image

Benefits at a glance

  • Simple, flexible integration into existing building structures
  • Extendible for long-lasting cost-effectiveness and future-proof investments
  • Optimum space utilisation, thanks to the flexible modular system
  • System-tested protection from potential physical threats
  • Compatible with cross-plant IT infrastructures


Examples of pre-defined solution packages.
Micro Data Center, 47 Uits, 1200mm depth



Back to top

Container

Container Image

Benefits at a glance
Micro Data Center – high availability in a security safe

  • Customised container solutions on a platform basis
  • Predefined modules are individually compiled to create a container data centre
  • Pre-assembled container solutions can be up and running in next to no time.
  • Project planning by Rittal
  • Turnkey delivery of a field-tested solution complete with comprehensive documentation.

Container 3 Image

Standardised, off-the-shelf modules

Continuously growing data volumes are having a major impact on IT infrastructure. Demand for CPU and storage capacity is increasing at the same pace, which means that more and more servers and storage systems are needed, while the floorspace available for IT infrastructure has barely changed. Rittal’s data centres in containers offer the perfect solution, because the standardised RiMatrix Data Cubes are installed in a short time and the concept is individually tailored to your requirements.

Fully pre-configured modules in the RiMatrix S series offer a pioneering alternative to building your own data centre. They already include all the necessary components such as IT enclosure systems, power backup and distribution, climate control and monitory and security solutions.


Container 2 Image

RiMatrix S – the standardised data centre

  • Pre-configrued modules – ready for immediate installation of the IT equipment
  • Fully functional complete system including server and network enclosures, climate control, power distribution and backup, monitoring and optionally the DCIM (Data Center Infrastructure Management) wit RiZone
  • Peace of mind – due to documented system test of the entire module

Brochures

White Papers

References
IT

Selters: Rittal MDC safeguards processes in Westerwald
B.Braun: A data centre that meets Industry 4.0 requirements
WUND group: smooth and secure spa operations thyssenkrupp steel ist expanding ist IT with Rittal Edge Data Centers
Dubrovnik Airport: Rittal data centre ensures high availability
A future-proof data centre for Swiss railway operator SOB

IE

Xylem cuts operating costs with Rittal Blue e+ cooling units Cargill, Inc.:Guaranteeing process safety
ATR GmbH: Fit for the US market with UL certification

Tools

Rittal Tools 1 Image

Security, availability and efficiency are curfcial to the productive operation of a data centre. This calls for a comprehensive approach which addresses all the relevant requirements as well as the peripheral conditions in order to devise a suitable solution. As well as personalised advice, Rittal can also provide you with a comprehensive range of tools for selecting, configuring and monitoring all relevant parameters.

IT



Back to top

RiCs Configurator PDU

Rittal Tools 2 Image

The modular system of PDU variants from Rittal can be used to plan customer-specific PDU configurations that meet the majority of project requirements for an IT rack power supply.

Benefits:

  • List and visualise your configuration
  • Delivery times are shown transparently
  • Get direct pricing information when you log into the online shop



Back to top

Edge Data Center Configurator

Rittal Tools 3 Image

Rittal has developed a data centre for small and medium businesses, which allows them to configure complete, turnkey “private cloud” solutions very easily. The configurator is includes both the analysis and configuration of rack, climate control, power supply and security components.

Analyse:

  • Your data centre configuration in just a few steps
  • Standardised solution
  • CFD analyses for all configurations and load ranges
  • Tested redundancy response

Climate control:

  • Output range from 3 to 30 kW
  • Cooling: LCU DX or LCP DX

Power supply:

  • Power distribution: PDU, basic version 3 x 16 A (optional metered version)
  • UPS: N+1 redundant ABB Upscale (optional)

Security:

  • Monitoring: CMC III Processing Unit with temperature measurement and access control (optional)
  • Automatic door opening (optional)
  • Rack-based early fire detection (optional)



Back to top

IT Infrastructure selector

Rittal Tools 4 Image

The IT Infrastructure configurator provides Partners, System Integrators, System Engineers and final users with a straightforward overview of the Rittal IT Competence. It covers all IT product areas and suggests relevant and assigned key accessories.

Benefits:

  • All product segments in the data centre at a glance: Network/server racks, solutions for IT cooling, IT power and IT monitoring
  • For added value, suitable accessories are suggested in every segment.
  • The result is an individual IT infrastructure, ready for you to request a quote from Rittal.



Back to top

RiMatrix S Selector

Rittal Tools 5 Image

Your selector for standardised data centres for SMEs, branch concepts and flexible cloud applications. Your solution is configured on the basis of standardised data centre modules.

Benefits:

  • RiMatrix S at a glance
  • Explanation of the option packages
  • Efficiency calculation for your location
  • As the outcome, you can save your compiled RiMatrix S solution as a PDF file.



Back to top

Micro Data Center Configurator

Rittal Tools 6 Image

Configure your individual security safe and the various configuration components which will expand your safe into a fully fitted Micro Data Centre.

Benefits:

  • Your complete micro data centre in just a few steps
  • Individual selection of configuration components
  • When you have finished, you can request a quote for your current configuration



Back to top

IT-Cooling Calculator

Rittal Tools 7 Image

This calculator enables you to easily select Liquid Cooling Packages (LCPs) for the rack and series cooling of your IT infrastructure. The cooling capacity of LCPs is calculated on the basis of a variety of physical parameters such as water inlet temperature and water volume, as well as the server inlet air and exhaust air temperatures. The complete results of the calculation can be saved as a pdf file in order to document the project.

Benefits:

  • Calculation of the cooling output of LCPs
  • Consideration of the various physical parameters
  • Save your finished calculation as a PDF file

Industry



Back to top

RiCs Configurator VX 25

Rittal Tools 8 Image

For configuration, Rittal offers large enclosures in a range of sizes and designs. Materials, sizes and enclosure designs are tailored to all major requirement profiles. Benefit from the solution diversity of Rittal system accessories.

Rittal has bundled their innovative products from enclosures, power distribution, climate control and IT infrastructure. Please find below some impressions of our product portfolio.

Schaffhausen ABB

It's the result of a collaboration between ABB, HPE and Rittal: an all-in-one plug and play industrial data center solution that is specifically designed to run in industrial environments, to bring enterprise-grade IT capacity closer to its machine control and points of data collection.

RiMatrix Container

A time-saving alternative to custom-designed data centers, RiMatrix S represents a set of preconfigured, fully-compatible data center modules with well-define power consumption and efficiency ratings. The system is a coordinated ensemble of Rittal's racks, climate control products, power backup and distribution systems and monitoring equipment. Ideal for installations like SMEs, users can benefit from shorter lead times and the ability to tailor the modules to fit within existing building infrastructure.



PDU: Rittal presents the latest PDU generation.

Demand-based power distribution in the IT rack – Smart and secure. Whether you need a compact, basic power distribution unit or are monitoring the entire energy requirements of your server rack, switching each slot individually or conducting in-depth consumption analyses, we have the right solution to meet your needs.


The new one: the AX

New horizons –AE becomes AX: A modest range of enclosures developed into the world’s largest modular system for enclosure manufacture. Since Rittal was founded, the company’s impressive innovative strength has spawned numerous enclosure generations, with millions of units in use – always ahead of their time. The latest generation – the AX – is a response to the challenges of the Industry 4.0 era and is the new original.


The new one: the KX

System perfection: The new small enclosure KX offers maximum data quality and consistency in engineering, and flexibility and safety for a wide range of applications.


VX25 – The new symmetry from Rittal

Only ONE pitch pattern - Simple interior construction - Less complex – more possibilities - Simplified baying - Infinite baying possibilities - Quick-fit sealing


RiCS VX 25 Configuration System

It is possible to configure faster and better at Rittal for a long time now with the Rittal Configuration System. Always find the right accessories, place outbreaks and holes with 3D visualization, download the result and order immediately. Of course for free. Get started now!

Rittal 7859.000 Image

IT LED system light for IT rack systems and IT racks
AX
7859.000
Contact Us for Quote

Rittal 5509.11 Image
Rittal 7979.216 Image

PDU metered, 32A/1P CEE 24xC13 / 4xC19
SE8
7979.216
Contact Us for Quote
